Die Application Gallery bietet COMSOL Multiphysics® Tutorial- und Demo-App-Dateien, die für die Bereiche Elektromagnetik, Strukturmechanik, Akustik, Strömung, Wärmetransport und Chemie relevant sind. Sie können diese Beispiele als Ausgangspunkt für Ihre eigene Simulationsarbeit verwenden, indem Sie das Tutorial-Modell oder die Demo-App-Datei und die dazugehörigen Anleitungen herunterladen.
Suchen Sie über die Schnellsuche nach Tutorials und Apps, die für Ihr Fachgebiet relevant sind. Beachten Sie, dass viele der hier vorgestellten Beispiele auch über die Application Libraries zugänglich sind, die in die COMSOL Multiphysics® Software integriert und über das Menü File verfügbar sind.
Ein Tonpilz-Schallwandler wird für relativ niederfrequente Schallabstrahlung mit hoher Leistung verwendet. Er ist eine der beliebtesten Schallwandler-Konfigurationen für SONAR-Anwendungen. Der Schwinger besteht aus piezokeramischen Ringen, die zwischen einer Kopfmasse und einer Endmasse ... Mehr lesen
Continuous mixing is used in process equipment to mix components in a single pass. Compared to batch mixing, this operation has the advantage that the tank filling and emptying steps are eliminated, implying that the process can be run without interruptions. A disadvantage of continuous ... Mehr lesen
Dieses Modell bietet Ihnen die Möglichkeit, eine Vielzahl von Mischern zu bauen, indem Sie zwei gängige Gefäßtypen mit zwei Rührwerkstypen kombinieren. Die Mischer sind mit Schikanen versehene Behälter mit flachem und gewölbtem Boden und entweder mit Schaufelrädern oder Rushton-Turbinen. ... Mehr lesen
This example shows how the mixing capability of a stirred vessel can be evaluated. To efficiently reach the steady operational conditions the turbulent flow is solved for using a frozen rotor analysis, and a following time dependent simulation. When a quasi-steady flow field has ... Mehr lesen
This is a model of the Brüel and Kjær 4134 condenser microphone. The geometry and material parameters are those of the actual microphone. The modeled sensitivity level is compared to measurements performed on an actual microphone and shows good agreement. The membrane deformation, ... Mehr lesen
When cooking food, such as a patty, in convection ovens there is a trade off in the heating method. If the patty is heated at a low oven temperature the cooking is slow and the patty dries out, resulting in a poor taste. If the patty is heated rapidly at a high temperature, it is ... Mehr lesen
Vermeiden Sie wackelnde Fenster und verbessern Sie das Klangerlebnis durch sorgfältige Positionierung der Lautsprecher in Ihrem Raum. In diesem Tutorial wird der tiefe Frequenzgang eines Wohnzimmers für die Tieftöner von zwei Lautsprechern analysiert und die Eigenfrequenzen des Raums ... Mehr lesen
Eine ebene TE-polarisierte elektromagnetische Welle fällt auf ein Gold-Nanopartikel auf einem dielektrischen Substrat. Die Absorptions- und Streuquerschnitte des Partikels werden für einige verschiedene polare und azimutale Einfallswinkel berechnet. Das Modell berechnet zunächst ein ... Mehr lesen
This benchmark studies the nonlinear deformation of a spherical cap subjected to point load at center using 2D axisymmetric Solid Mechanics and Shell interfaces. The results from the Shell interface are compared with Solid Mechanics interface as well as with analytical results given in ... Mehr lesen
Using a Fluid-Solid Interaction multiphysics interface, the behavior of a spring-loaded ball check valve is studied under varying functional and reverse flow. The fluid force acting on the ball opens the valve at the opening pressure. In the case of a reversed pressure, the ball comes ... Mehr lesen
