Die Application Gallery bietet COMSOL Multiphysics® Tutorial- und Demo-App-Dateien, die für die Bereiche Elektromagnetik, Strukturmechanik, Akustik, Strömung, Wärmetransport und Chemie relevant sind. Sie können diese Beispiele als Ausgangspunkt für Ihre eigene Simulationsarbeit verwenden, indem Sie das Tutorial-Modell oder die Demo-App-Datei und die dazugehörigen Anleitungen herunterladen.
Suchen Sie über die Schnellsuche nach Tutorials und Apps, die für Ihr Fachgebiet relevant sind. Beachten Sie, dass viele der hier vorgestellten Beispiele auch über die Application Libraries zugänglich sind, die in die COMSOL Multiphysics® Software integriert und über das Menü File verfügbar sind.
This model demonstrates the use of the Two-Phase Thin-Film Flow, Phase Field multiphysics coupling, which can be used to predict the evolution of an interface between two different, immiscible fluids in thin, narrow channels. The example here presents a free boundary lubrication ... Mehr lesen
Turbulent flow, Elliptic Blending R-ε interface is used to analyze fully developed turbulent flow in a spanwise rotating channel. Due to the influence of Coriolis force on turbulence, profiles of the flow variables are skewed at moderate rotation rate. The asymmetry between cyclonic ... Mehr lesen
A small building block of integrated photonics, i.e., a Silicon-on-Insulator taper, is considered. For a larger system design, it might be useful to determine the phase delay such a device introduces. Here, we showcase the layout needed to do it in COMSOL, including a proper Port ... Mehr lesen
This example uses the Granular Flow interface to model the formation of the grain heap and then its subsequent spreading using a cylindrical roller. The roller has a combined rotational and translational motion. The resulting powder bed is then analyzed to determine its quality based on ... Mehr lesen
This model uses the Granular Flow and Membrane interfaces to simulate the packing of spherical grains in a flexible container, a procedure often found in the processing industry. In this example, grains are packed into a cubic container constructed of a thin polymer fabric. Two packing ... Mehr lesen
PCB is fabricated by laminating multiple materials, such as FR-4, copper, and resin, which exhibit significantly different coefficients of thermal expansion (CTE). When subjected to heating, the differential thermal expansion among these layers induces interlaminar deformation mismatch, ... Mehr lesen
This model simulates a holographic page data storage system. The studies include the recording and retrieval processes. The object beam encrypting 8-bit data is focused into a holographic material by a Fourier lens (Fourier transformation). In the recording process, the object beam ... Mehr lesen
Manual design optimization typically requires numerous sweeps over a parameterized geometry, but it does not guarantee optimal performance under given conditions. Shape optimization removes the need for explicit parameterization and can achieve comparable or even better performance in a ... Mehr lesen
This example model demonstrates four different approaches for computing the integrals of fields over arbitrarily placed geometries that can be re-positioned without having to re-solve the model. This approach is also useful if you want to integrate the results of a model over different ... Mehr lesen
This tutorial demonstrates how to model a Silicon-on-Insulator (SoI) Modulator – a well-known optics device configuration that takes advantage of the free-carrier plasma dispersion effect and allows for the electrical control of the optical waveguide properties. The simulation couples ... Mehr lesen
