Die Application Gallery bietet COMSOL Multiphysics® Tutorial- und Demo-App-Dateien, die für die Bereiche Elektromagnetik, Strukturmechanik, Akustik, Strömung, Wärmetransport und Chemie relevant sind. Sie können diese Beispiele als Ausgangspunkt für Ihre eigene Simulationsarbeit verwenden, indem Sie das Tutorial-Modell oder die Demo-App-Datei und die dazugehörigen Anleitungen herunterladen.
Suchen Sie über die Schnellsuche nach Tutorials und Apps, die für Ihr Fachgebiet relevant sind. Beachten Sie, dass viele der hier vorgestellten Beispiele auch über die Application Libraries zugänglich sind, die in die COMSOL Multiphysics® Software integriert und über das Menü File verfügbar sind.
This example demonstrates how to apply inverse uncertainty quantification (IUQ) using the Uncertainty Quantification (UQ) Module in COMSOL Multiphysics to calibrate uncertain material properties of a resistor based on measurement data. When experimental data such as resistance values are ... Mehr lesen
In semiconductor manufacturing, vacuum chucks are used to rapidly and contamination-free adsorb and secure wafers before processes such as transfer, lithography, and inspection. Traditional empirical design makes it difficult to quantify the effects of groove shape, size, distribution, ... Mehr lesen
In direct bonding, if the interface is not clean and particles are present, even particles on the micron scale can significantly degrade the bonding quality, resulting in large-area voids. This model demonstrates the simulation process of 3D D2W direct bonding, taking into account the ... Mehr lesen
This app generates random surfaces based on imported CAD models. Surfaces can be created using Gaussian or uniform random fields, analytical expressions, or combinations of random and deterministic fields. The app provides extensive customization options for controlling roughness, ... Mehr lesen
This example demonstrates how to model a variable-angle tow (VAT) laminate in which the fiber orientation varies linearly along the global x-direction, with each layer assigned its own fiber angle. The results obtained using the Layered Shell interface are compared with a full 3D ... Mehr lesen
This example demonstrates the optimization of fiber orientation in a variable angle tow (VAT) laminate to maximize stiffness under prescribed loading and boundary conditions. The composite laminate consists of a single layer of carbon–PEEK composite with transversely isotropic material ... Mehr lesen
In electrosurgery, high-power AC current from a probe is driven into tissue in order to cut and coagulate it. The current causes rapid Joule heating near the tip, and as temperatures reach 100°C, water and blood vaporize and the tissue desiccates, enabling cutting or sealing. This ... Mehr lesen
PCB is fabricated by laminating multiple materials, such as FR-4, copper, and resin, which exhibit significantly different coefficients of thermal expansion (CTE). When subjected to heating, the differential thermal expansion among these layers induces interlaminar deformation mismatch, ... Mehr lesen
This model demonstrates isoelectric focusing (IEF) of seven ampholytes in a column. The model is in 1D and is solved in a time-dependent simulation. Mehr lesen
Galvanostatic Intermittent Titration Technique (GITT) is commonly used to estimate the solid-phase lithium diffusion coefficient in electrode particles. In this example, a half-cell model is built using the Lithium-Ion Battery interface, and imported synthetic voltage datasets at ... Mehr lesen
