Veröffentlichungen und Präsentationen

Hier finden Sie Veröffentlichungen und Präsentationen der weltweit stattfindenden COMSOL-Konferenzen. In diesen präsentieren Ihre Fachkollegen ihre neuesten mit COMSOL Multiphysics entwickelten Produkte und Ideen. Die Forschungsthemen umfassen ein weites Feld von Industrien und Anwendungsbereichen, die von Mechanik und Elektronik über Strömungen bis zur Chemie reichen. Nutzen Sie die Quick Search, um die zu Ihrem Forschungsbereich passenden Präsentationen zu finden.

Simulation of Impact Damage in a Composite Plate and Its Detection

V. Pavelko[1], I. Pavelko[1], M. Smolyaninovs[1], H. Pffeifer[2], M. Wevers[2]
[1]Riga Technical University, Riga, Latvia
[2]Catholic University Leuven, Leuven, Belgium

A problem of damage prediction in aircraft structure and its non-destructive evaluation is very important for aircraft structural health assessment. The analysis of the features of direct impact of thin-walled laminate component of aircraft was performed by COMSOL Multiphysics software. Mainly the GFRC and CFRC laminates were selected in form either thin separate plate or sandwich structure. The ...

Improved Perfectly Matched Layers for Acoustic Radiation and Scattering Problems

M. Zampolli[1], N. Malm[2], and A. Tesei[1]
[1]NURC NATO Research Centre, La Spezia, Italy
[2]COMSOL AB, Stockholm, Sweden

Perfectly matched layers (PML) are an efficient alternative for emulating the Sommerfeld radiation condition in the numerical solution of wave radiation and scattering problems. The key ingredient of the PML formulation is the complex scaling function, which controls the anisotropic damping of the PML. The objective of this study is to propose a modified complex scaling function capable of ...

Modeling Acoustic Interface Wave Dispersion Using COMSOL Multiphysics®

B. Goldsberry[1], M. Isakson[1]
[1]Applied Research Laboratories, The University of Texas at Austin, Austin, TX, USA

Measuring geoacoustic parameters of underwater sediments is important for accurate modeling of underwater acoustic propagation. While the density and compressional wave speeds can be directly measured in sediments, shear wave speeds are difficult to measure because they are highly attenuated. However, shear wave speeds can be indirectly determined through measurement of Scholte interface wave ...

Modeling and Testing of Carbon-Fiber Doubly-Resonant Underwater Acoustic Transducer

A. Morozov[1]
[1]Teledyne Technologies Inc., Falmouth, MA, USA

This paper describes the COMSOL Multiphysics® simulation and the test of a low-frequency (500Hz) sound source for long-range acoustic communications. This design uses innovative carbon-fiber composite materials.To meet the demand for the frequency range the doubly resonant organ pipe resonator was suggested. A multi-resonant system usually needs a precise, complicated adjustment of its ...

SAW Sensors for Surgical Arm using Piezoelectric Devices

Rakesh Kumar Pati [1], SK Mohammed ali[1], Sakuntala Mahapatra[1], Millee Panigrahi[1]
[1]MEMS Design Centre, Dept. of ETC, Trident Academy of Technology, Bhubaneswar, Odisha, India

Despite of the existing successful clinical applications, however, the interaction, i.e. artificial sensing, between the robot and the patient is still very limited. With the help of various cameras, vision is almost the only feeling that a robot can have. In order to imitate the human skin, various signals e.g., the strength of pressure, change of strength, speed and acceleration should be ...

Design and Optimization of a High Performance Ultrasound Imaging Probe Through FEM and KLM Model

L. Spicci, and M. Cati
Esaote SpA
Florence, Italy

The present paper describes the development of a full FEM model for linear array high performance 5MHz ultrasound imaging transducer. As a preliminary design, a mono dimensional electro-acoustical KLM model was realized, then the complete FEM was developed and optimized. The optimized transducer was manufactured, so that agreement between transducer measured performances and simulation results ...

A MEMS Condenser Microphone for Consumer Applications

S. L. Pinjare, V. S. Nagaraj, S. N. Savitha, S. Kesari, M. S. Sagar, and K. R. Roshan
Nitte Meenakshi Institute of Technology

The MEMS microphone is also called microphone chip or silicon microphone. The pressure sensitive diaphragm is etched directly into a silicon chip by MEMS techniques and is usually accompanied with integrated preamplifier. Most MEMS microphones are variants of the condenser microphone design. The MEMS microphone has been successfully fabricated and tested in an anechoic chamber. The microphone ...

Acoustic Field Comparison of High Intensity Focused Ultrasound Using Experimental Characterization and Finite Element Simulation

J. L. Teja[1], A. Vera[1], L. Leija[1]
[1]Department of Electrical Engineering, Cinvestav-IPN, Mexico D.F., Mexico

High Intensity Focused Ultrasound (HIFU) is used as a noninvasive technique of tissue heating and ablation for different medical treatments. This paper presents a quantitative comparison of HIFU acoustic fields experimentally obtained versus simulated acoustic fields. Acoustic field characterization was realized in two HIFU transducers using water as a propagation medium. Also, simulations were ...

Mapping Local Cavitation Events in High Intensity Ultrasound Fields

V. Raman [1], A. Abbas[2], and S.C. Joshi[2]
[1] Indian Institute of Technology, Madras
[2] Nanyang Technological University, Singapore

The linear acoustic pressure field is obtained by solving the homogenous Helmholtz equation using COMSOL Multiphysics. The pressure field is used to calculate the collapse pressure of the transient cavitation bubbles by using the cavity cluster approach. The regions where the local pressure exceeds the Blake threshold are potential regions of transient cavitation events. The ultrasound ...

Acoustical Design of Stethoscope for Improved Performance

C. Thiagarajan[1], Gururajan R.[2], A. H. Baig[2], Prema S.[3]
[1]ATOA Scientific Technologies Pvt Ltd, Whitefield, Bangalore, Karnataka India
[2]University of Southern Queensland, Toowoomba Qld 4350, Australia.
[3]RMK Engineering College, Chennai, Tamil Nadu, India

Stethoscope is in use for more than 200 years for medical diagnostics, especially for auscultation. Recently, the unprecedented growth in mobile technology revived the use of stethoscope for Telehealthcare. Digital or electronic stethoscopes are increasingly researched for use in Telehealthcare. This paper mainly focuses on the acoustical and multiphysics design aspects of the stethoscope for ...
