Die Application Gallery bietet COMSOL Multiphysics® Tutorial- und Demo-App-Dateien, die für die Bereiche Elektromagnetik, Strukturmechanik, Akustik, Strömung, Wärmetransport und Chemie relevant sind. Sie können diese Beispiele als Ausgangspunkt für Ihre eigene Simulationsarbeit verwenden, indem Sie das Tutorial-Modell oder die Demo-App-Datei und die dazugehörigen Anleitungen herunterladen.
Suchen Sie über die Schnellsuche nach Tutorials und Apps, die für Ihr Fachgebiet relevant sind. Beachten Sie, dass viele der hier vorgestellten Beispiele auch über die Application Libraries zugänglich sind, die in die COMSOL Multiphysics® Software integriert und über das Menü File verfügbar sind.
Delamination or the separation of layers is a common failure mode in laminated composite materials. Various factors, including loading, defects in the material, and environmental conditions can trigger the initiation and propagation of layer separation. This leads to degraded structural ... Mehr lesen
Tilted pad thrust bearings are used in rotating machineries with high thrust loading. The thrust load is transferred from a sliding part to a stationary part through hydrodynamic oil films. The tilted pad thrust bearing consists of a series of flat surfaces sliding over stationary tilted ... Mehr lesen
It is often not possible to insert a normal microphone directly into the sound field being measured. The microphone may be too big to fit inside the measured system, such as for in-the-ear measurements for hearing aid fitting. The size of the microphone may also be too large compared to ... Mehr lesen
In dieser Tutorial-Serie erfahren Sie, wie Sie mit importierten Oberflächennetzen arbeiten können. Die Anleitung beschreibt, wie Sie STL-Dateien von zwei Wirbeln und einer Bandscheibe importieren und wie Sie Löcher, falsch ausgerichtete Netzpunkte und sich überschneidende Elemente ... Mehr lesen
Solving very large pressure acoustics models in the frequency domain can be challenging. Several iterative solver suggestions exist for the default physics setups and the default quadratic Lagrange discretization. For very large models it can be advantageous to switch from quadratic to ... Mehr lesen
This model simulates an H-shaped micro-cell designed for diffusion-controlled separation. The cell puts two different laminar streams in contact for a controlled period of time. The contact surface is well-defined and, by controlling the flow rate, it is possible to control the amount of ... Mehr lesen
Squeezed-film gas damping is a critical aspect of many MEMS transducers and actuators. In accelerometers, for example, inertia produces a motion that the device detects. A typical structure connects a large proof mass to surrounding structures with elastic beams, which forms a mechanical ... Mehr lesen
When high-fidelity measurement microphones are calibrated, a pressure reciprocity calibration method is used. During calibration, two microphones are connected at each end of a closed cylindrical cavity. For the calibration procedure, it is important to understand the acoustic field ... Mehr lesen
Fiber composites are widely used in industrial applications. Compared to more traditional metallic engineering materials, fiber composites often have superior specific stiffness and strength properties, and they are often more corrosion resistant. Also, properties like strength, ... Mehr lesen
Dieses Modell veranschaulicht die Analyse einer starken Windströmung um ein Solarpanel und die entsprechende strukturelle Verschiebung aufgrund der Windlast. Das Solarpanel befindet sich in einer Anordnung von identischen Paneelen mit gleichem Abstand, was die Annahme zulässt, dass die ... Mehr lesen
