Die Application Gallery bietet COMSOL Multiphysics® Tutorial- und Demo-App-Dateien, die für die Bereiche Elektromagnetik, Strukturmechanik, Akustik, Strömung, Wärmetransport und Chemie relevant sind. Sie können diese Beispiele als Ausgangspunkt für Ihre eigene Simulationsarbeit verwenden, indem Sie das Tutorial-Modell oder die Demo-App-Datei und die dazugehörigen Anleitungen herunterladen.
Suchen Sie über die Schnellsuche nach Tutorials und Apps, die für Ihr Fachgebiet relevant sind. Beachten Sie, dass viele der hier vorgestellten Beispiele auch über die Application Libraries zugänglich sind, die in die COMSOL Multiphysics® Software integriert und über das Menü File verfügbar sind.
Eine akustische Oberflächenwelle (surface acoustic wave, SAW) ist eine akustische Welle, die sich entlang der Oberfläche eines festen Materials ausbreitet. Ihre Amplitude nimmt in der Tiefe des Materials schnell, oft exponentiell, ab. SAWs werden in vielen Arten von elektronischen ... Mehr lesen
This example models heat generation in a beam-like structure subjected to small amplitude vibrations. The model computes the linear elastic response in the frequency domain. The transient heat-transfer analysis simulates the slow-rising temperature in the beam using the heat generated ... Mehr lesen
Die Akustik von Flüssigkeiten oder Gasen, die an strukturelle Objekte wie Membranen, Platten oder Festkörper gekoppelt sind, sind wichtige Anwendungen in vielen technischen Bereichen. Dieses Modell ist eine allgemeine Demonstration eines akustischen Fluid-Phänomens in 3D, das an ein ... Mehr lesen
A solidly-mounted resonator (SMR) is a piezoelectric MEMS resonator formed on top of an acoustic mirror stack deposited on a thick substrate. This tutorial shows how to simulate an SMR in 3D. In this example, the eigenmodes were computed with varying number of particles attached to the ... Mehr lesen
In this shape optimization example, the mass of a bracket is minimized by changing the size and position of a number of geometrical objects. The requirements give limits both on the lowest natural frequency, and on the maximum stress in a static load case. This means that results from ... Mehr lesen
An electrostatically actuated MEMS resonator is simulated in the time and frequency domains. The device is driven by an AC + DC bias voltage applied across a parallel plate capacitor. The dependence of the resonant frequency on DC bias is assessed, and frequency domain and transient ... Mehr lesen
Uncertainty Quantification is used to study the effect of manufacturing variation on the performance of 2D Solidly Mounted Resonator (2D SMR). This tutorial shows how resonant frequency is effected by thickness variations of the piezoelectric layer and the Bragg reflector layers. The ... Mehr lesen
This tutorial example shows how to perform a random vibration analysis of a structure using power spectral density (PSD). The computations are based on the modal reduced order model (ROM). Mehr lesen
This example explores the shift in natural frequencies caused by changing the temperature. One study investigates a doubly clamped beam where both ends are fixed, while the other study looks at a cantilever beam where only one end is fixed. The following effects are studied: Stress ... Mehr lesen
This model demonstrates how to design a beam without low Eigenfrequencies by combining the Density Model feature in the Topology Optimization interface with the Stationary Then Eigenfrequency study step. Mehr lesen
