G. R. Prakash, K. M. V. Swamy, S. Huddar, B. G. Sheeparamatti, Kirankumar B. B.
Basaveshwar Engineering College, Bagalkot, Karnataka, India
The focus of this paper is to study the effect on resonance frequency and power enhancement techniques of piezoelectric MEMS and modeling, design, and optimization of a piezoelectric generator based on a two-layer bending element(Figure 1) using COMSOL Multiphysics. An analytical relation was developed based on the shift in resonance frequency(Figure 2) caused by the addition of a thin film ...
E. Rawashdeh, A. Arevalo, D. Castro, I. G. Foulds, N. Dechev
Computer, Electrical & Mathematical Sciences & Engineering Division (CEMSE), King Abdullah University of Science & Technology, Thuwal, Saudi Arabia
School of Engineering, Okanagan Campus, The University of BC, Vancouver, BC, Canada
University of Victoria, Victoria, BC, Canada
In this work we present the simulation of a micro-scale large displacement compliant mechanism called the Tsang suspension. It consists of a flat micro-plate anchored down by two springs on either side, that can rotate out-of-plane and maintain its vertical assembly by a simple single-axis actuation. COMSOL Mutliphysics® software was used to simulate these devices and extract the reaction forces ...
L. Sujatha, B. Preethi
Rajalakshmi Engineering College, Chennai, India
MEMS gyroscope technology provides cost- effective method for improving directional estimation and overall accuracy in the navigation systems. This paper presents a tuning- fork gyroscope (TFG)  with a perforated proof mass. The perforated proof mass used in the design enables the reduction of the damping effect. This MEMS based gyroscope was designed using COMSOL Multiphysics 4.2a. This ...
K. Al-Shurman, H. Naseem
The Institute for Nanoscience & Engineering, University of Arkansas, Fayetteville, AR, USA
Department of Electrical Engineering, University of Arkansas, Fayetteville, AR, USA
Chemical vapor deposition is considered a promising method for synthesis of graphene films on different types of substrate utilizing transition metals such as Ni. However, synthesizing a single-layer graphene and controlling the quality of the graphene CVD film on Ni are very challenging due to the multiplicity of the CVD growth conditions. COMSOL Multiphysics® software is used to investigate ...
J. Crompton, S. Yushanov, L.T. Gritter, K.C. Koppenhoefer
AltaSim Technologies, Columbus, OH, USA
The resonance conditions for surface plasmons are influenced by the type and amount of material on a surface. Full insight into surface plasmon resonance requires quantum mechanics considerations. However, it can be also described in terms of classical electromagnetic theory by considering electromagnetic wave reflection, transmission, and absorption for the multi-layer medium. The two commonly ...
S. Gupta, T. Pahwa, R. Bansal, V. Bansal, B. Prasad, D. Kumar
Electronic Science Department Kurukshetra University, Kurukshetra, Haryana
A new design of electrostatic comb drive actuator is presented in this paper by using different spring designs and with different folded beam lengths. An increased displacement of lateral comb drive actuator will subsequently be accomplished with the same actuation voltage. Stress distribution over different spring designs are simulated by COMSOL 3.5a using a standard comb drive with 4 movable ...
H. S. Shriram, T. Nimje, D. Vakharia
BITS Pilani, Rajasthan, India
Radio Frequency MEMS devices have emerged to overcome the problem of high losses associated with semiconductors at high frequencies. A tunable MEMS capacitor is a micrometre-scale electronic device whose capacitance is controlled through different actuation mechanisms which govern the moving parts. It can have electrostatic or electrothermal actuators depending on the functional complexity and ...
S. Gorelick, M. Leivo, U. Kantojärvi
VTT Technical Research Centre of Finland, Espoo, Finland
Excessive air damping can be detrimental to the performance of oscillating MEMS components. Complex systems, such as structures in pre-etched cavities or angular comb-drive scanning mirrors, typically require simulations to reliably evaluate the air damping. The simulated and experimental performance of the following systems was evaluated and compared: two types of out-of-plane cantilevers, in ...
P. Graak , S. Kaur , A. Gupta , P. Chhabra , D. Kumar , A. Shetty
 Kurukshetra University, Kurukshetra, Haryana, India
 Indian Institute of Science, Bengaluru, Karnataka, India
The ambient vibrations can be of great promise for harvesting energy initially at small scale to use for micro and nano scale devices. Such vibrations converted to electrical energy by piezoelectric transducer due to their major significance. Various research journals have introduced the phenomenon of energy optimization to increase the generated power and used directly for application like ...
S. L. Pinjare, V. S. Nagaraj, S. N. Savitha, S. Kesari, M. S. Sagar, and K. R. Roshan
Nitte Meenakshi Institute of Technology
The MEMS microphone is also called microphone chip or silicon microphone. The pressure sensitive diaphragm is etched directly into a silicon chip by MEMS techniques and is usually accompanied with integrated preamplifier. Most MEMS microphones are variants of the condenser microphone design. The MEMS microphone has been successfully fabricated and tested in an anechoic chamber. The microphone ...
