Die Application Gallery bietet COMSOL Multiphysics® Tutorial- und Demo-App-Dateien, die für die Bereiche Elektromagnetik, Strukturmechanik, Akustik, Strömung, Wärmetransport und Chemie relevant sind. Sie können diese Beispiele als Ausgangspunkt für Ihre eigene Simulationsarbeit verwenden, indem Sie das Tutorial-Modell oder die Demo-App-Datei und die dazugehörigen Anleitungen herunterladen.
Suchen Sie über die Schnellsuche nach Tutorials und Apps, die für Ihr Fachgebiet relevant sind. Beachten Sie, dass viele der hier vorgestellten Beispiele auch über die Application Libraries zugänglich sind, die in die COMSOL Multiphysics® Software integriert und über das Menü File verfügbar sind.
Die Lösung sehr großer Druckakustikmodelle im Frequenzbereich kann eine Herausforderung darstellen. Für die Standard-Physikkonfigurationen und die standardmäßige quadratische Lagrange-Diskretisierung gibt es mehrere Vorschläge für iterative Löser. Bei sehr großen Modellen kann es ... Mehr lesen
This is a demo model to show how to model connections in a mechanical system using Multibody Dynamics interface. In this model, pantograph mechanism is modeled. The purpose of this mechanism is to produce an identical, either enlarged or miniaturized, copy of an existing drawing. Mehr lesen
Mechanical precession prevents bicycle pedals from falling off. The model captures this effect using a multibody dynamics simulation together with a contact analysis. A friction coefficient is associated with the contact in order for the model to capture the effect. Mehr lesen
Stimulated Brillouin Scattering (SBS) describes a nonlinear interaction between light and sound. In optical fibers, SBS can be detrimental for power or communication purposes, but can be leveraged for sensing applications. The SBS gain spectrum quantifies the optic-acoustic mode ... Mehr lesen
The electrodes of a lithium-ion battery are porous, consisting of an active solid material, a binder, and pores filled with liquid electrolyte. If a force is applied on the porous layers of a battery, this will affect the volume fraction of the electrolyte-filled pores in the electrodes, ... Mehr lesen
This parametrized model can be used to simulate the hopping hoop problem. A rolling ring with a point mass on the perimeter can, under certain conditions, jump up from the surface on which it is rolling. A more detailed description of this model can be found in the blog post "The ... Mehr lesen
This model uses the Granular Flow and Membrane interfaces to simulate the packing of spherical grains in a flexible container, a procedure often found in the processing industry. In this example, grains are packed into a cubic container constructed of a thin polymer fabric. Two packing ... Mehr lesen
The dipole tonal noise generated by flow over a cylinder in free space is modeled using a two step hydrodynamic/acoustic splitting method. First, the unsteady hydrodynamic flow field is calculated using the incompressible Navier-Stokes equations. Second, the Linearized Perturbed ... Mehr lesen
A highly simplified pedestrian bridge is for simplicity imagined to consists of a concrete slab on supported by three I-beams. The design is to be evaluated for peak acceleration due to walking. The model analyzes uncertainty in peak acceleration due to some material damping properties ... Mehr lesen
This model analyzes the uncertainty in focused ultrasound induced tissue heating. The material properties for the tissue mimicking material, including the uncertainty, are taken from the FDA Medical Device Development Tool: Tissue Mimicking Material (TMM) for Preclinical Acoustic ... Mehr lesen
